Product Description

UNI FAN SL-INFINITY

Software controlled fan speed/ LED lighting

Only one cable is required for a cluster of fans

Embedded magnetic Fluid Dynamic Bearing to provide stability, durability, and longevity

40 LEDs in each fan

Quick PIN connection to provide ease of installation

Low noise level at high RPM

Infinity mirror look all around


Infinity Mirror ARGB Fan

Introducing a new look to PC fans and a new level of installation simplicity and light effect customizability.


INFINITY MIRROR FAN

A combination of the original UNI FAN SL and AL with a touch of infinity mirror, the SL-Infinity fans glow clear with multi-layer effects from any visible angle.


CENTERED INFINITY MIRROR ARGB

The circular-shaped infinity mirror at the center of the fan is tuned to have multiple layers spaced 0.5mm apart.


SIDE FRAME ARGB

Following the iconic angular lighting style of SL fans, the SL-Infinity fans have 2 thin LED strips on both sides of the fan blade.


ALUMINUM TRIM SURROUNDED INFINITY MIRROR

Surrounding aluminum trims are located on both sides of the frame. The geometric shape of the infinity mirror follows the front ARGB lighting strip in a top and bottom pattern that creates a 3D indented look.
PRODUCT NAME
LIAN LI UNI FAN SL-INF 140 RGB
COLOR
Black
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
1 4-PIN PWM + 3-PIN ARGB
FAN DIMENSION
140 X 142 X 25 (mm)
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
FAN SPEED
0,200 to 1600 RPM
MAX. AIR PRESSURE
2.88 mmH2O (Maximum)
MAX. AIRFLOW
72.7 CFM (Maximum)
ACOUSTIC NOISE
28 dB(A) Max
LOCKED CURRENT
is more than or equal to 40mA
BEARING TYPE
Fluid Dynamic Bearing (FDB)
START-UP VOLTAGE
DC is less than or equal to 6V
INPUT CURRENT
150mA (FAN) / 600mA(LED)
INPUT POWER
4.56w
Item Dimension (L inchxW inchxH inch)
7 x 2 x 7

Weight
1.00 lb

Warranty Information
2 year

Available Quantity

5

UPC

840353043992

SKU

mingleUF-SLIN140-1B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN SL V2
Improved daisy chain design to connect 2 clusters of fans.
SL120 V2 fan frame thickness is 28mm to provide 10% improved airflow compared to V1.
Removable interlocking keys to provide better radiator clearance.
Start/stop fan RPM support for a quieter environment.
Smoother side lighting for a better aesthetic.
Only one cable is required for each fan cluster when using the provided new UNI HUB to control lighting effects via L-Connect 3.
AVAILABLE IN TWO SIZES AND TWO COLORS
White / Black
SL120 V2
Black / White
SL140 V2
UPGRADED MODULARITY
UNI FAN SL V2 revised its interlocking style to connect up to 6 fans in two clusters to a single controller port, making cable management simpler.
Extension Cable
With the new 18 cm extension cable, the ability to bridge two clusters of fans to create a 3+3 daisy-chained cluster is offered. These 6 fans can then be connected to a single port on the SL V2 UNI HUB controller. The new daisy-chaining solution reduces the number of cables needing to be managed at the back of the case and enables new lighting effects which can be continuous between the two bridged clusters.
PRODUCT NAME
UNI FAN SL V2 140
MODEL
SL140V2-1B
COLOR
Black
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
1 x 4-PIN PWM
+ 3-PIN SM Type
1 x ARGB MB Adaptor
MATERIAL
PBT/PC/Aluminum)
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
FAN DIMENSION
140 X 140 X 25 (mm)
FAN SPEED
0, 250-1600 RPM
MAX. AIR PRESSURE
2.09 mmH2O (Maximum)
MAX. AIRFLOW
77.6 CFM (Maximum)
ACOUSTIC NOISE
29 dB(A) Max
LOCKED CURRENT
0 (Automatic Protection)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
START-UP VOLTAGE
less than or equal 5V
INPUT CURRENT
0.11A
INPUT POWER
1.32W
Item Dimension (L"xW"xH")
7 x 2 x 7

Weight
1 lb

Warranty Information
2 years

Available Quantity

5

UPC

840353043497

SKU

mingleUF-SL140V2-1B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN SL V2

Improved daisy chain design to connect 2 clusters of fans.

SL120 V2 fan frame thickness is 28mm to provide 10% improved airflow compared to V1.

Removable interlocking keys to provide better radiator clearance.

Start/stop fan RPM support for a quieter environment.

Smoother side lighting for a better aesthetic.

Only one cable is required for each fan cluster when using the provided new UNI HUB to control lighting effects via L-Connect 3.

AVAILABLE IN TWO SIZES AND TWO COLORS

White / Black

SL120 V2

Black / White

SL140 V2

UPGRADED MODULARITY

UNI FAN SL V2 revised its interlocking style to connect up to 6 fans in two clusters to a single controller port, making cable management simpler.

Extension Cable

With the new 18 cm extension cable, the ability to bridge two clusters of fans to create a 3+3 daisy-chained cluster is offered. These 6 fans can then be connected to a single port on the SL V2 UNI HUB controller. The new daisy-chaining solution reduces the number of cables needing to be managed at the back of the case and enables new lighting effects which can be continuous between the two bridged clusters.
PRODUCT NAME
UNI FAN SL V2 120
MODEL
SL120V2-3B
COLOR
Black
NUMBER OF FANS
3
CONTROLLER
Yes
CONNECTOR TYPE
4 x 7-PIN
(Power Cable)
2 x Extension Cable
MATERIAL
PBT/PC/Aluminum)
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
FAN DIMENSION
120 X 120 X 28 (mm)
FAN SPEED
0, 250-2000 RPM
MAX. AIR PRESSURE
2.59 mmH2O (Maximum)
MAX. AIRFLOW
64.5 CFM (Maximum)
ACOUSTIC NOISE
29.2 dB(A) Max
LOCKED CURRENT
0 (Automatic Protection)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
START-UP VOLTAGE
less than or equal 5V
INPUT CURRENT
0.17A
INPUT POWER
2.04W
Item Dimension (L"xW"xH")
7 x 5 x 6

Weight
2.0 lb

Warranty Information
2 years

Available Quantity

5

UPC

840353043398

SKU

mingleUF-SL120V2-3B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

RM42300

4U 17.5" Compact Industrial Server Chassis

Equipped with shock isolated design solution, dust-proof filter on compact chassis size make it ideal for space constrained industrial applications.

Features & Benefits

Supports M/B up to 12 x 9.6

Available for rackmount and stand-alone installation

Dedicated 80 mm fan for center front HDD cooling

Shock isolated dampener solution on internal HDD and device protection

Card retainer to hold low profile and full height add-on cards

Front 120mm fan with filter for add-on card cooling

Optional second 3 x 5.25 drive cage for maximum configuration flexibility

Supports 1-door or 2-door front bezel configuration

Supports PS/2 single or mini-redundant PSU
Form Factor
4U
MB Form Factor
ATX (12 x 9.6)
Drive Bays
External 3.5"1
External 5.25"3
Internal 3.5"4
Slim ODD1
PSU Form Factor
PS/2 Single or Mini-redundant
Indicators
1 x Power Status
1 x HDD Activity
2 x LAN Activity
Front Control
1 x Power On/Off
1 x System Reset
2 x USB 2.0/USB3.0(option)
System Security
Intrusion Switch, Key lock on front door
Cooling Fans
Front: 1 x 120mm (T equal 25mm), PWM, Rear: 2 x 80mm (T equal 25mm)(Option)
Expansion Slots
7
HDD Backplane
N/A
Front Bezel
Option
Item Dimension (L"xW"xH")
NA

Weight
28 lbs

Warranty Information
1 Year

Available Quantity

5

UPC

808613502498

SKU

mingleRM42300H11*13739

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Kraken Elite 360

360mm AIO Liquid Cooler with LCD Display


Get high-performance cooling, display a favorite animated GIF or static image, monitor real-time PC performance metrics, see music that's currently playing, stream browser content and more with NZXT CAM software.

2.36" diameter wide-angle LCD display with 640x640 resolution and 60 Hz refresh rate provides a sharp image from any viewing angle

Screen supports the display of custom images, animated GIFs, and CAM system info with adjustable orientation

Powerful Asetek pump provides optimal cooling and up to 2,800 RPM whisper-quiet operation

Includes F140P/F120P Static Pressure fans

Single breakout cable simplifies installation

Rubber tubing is reinforced with nylon-braided sleeves to prevent leaks

Control custom screen content, pump speed, and zero-noise fan curves with NZXT CAM



Inside the Box

Kraken Elite 360: 1

F120P fan: 3

Installation Accessories: 1

Breakout cable set
CAP
Material:
Aluminum and plastic
Display Orientation:
Software adjustable Default, +90, +180, and -90 Degrees
Display Panel Active Area:
2.36" (60mm) diameter
Display Color:
24-bit true color LCD
Display Resolution:
640 x 640 px
Display Brightness:
690 cd/m²
Display Panel Type:
TFT-LCD (Wide Viewing Angle)
WATER BLOCK
Material:
Block: Copper Housing: Plastic
PUMP
Motor Speed:
800 - 2,800 +/- 300RPM
Power:
12V DC, 0.3A
RADIATOR
Material:
Aluminum
TUBE
Length:
400mm
Material:
Ultra-low Evaporation Rubber with Nylon Braided Sleeve
FAN SPECS
Model:
F120P Static Pressure Fan
Quantity:
3
Dimension:
120 x 120 x 26mm
Speed:
500-1,800 +/- 180 RPM
Air Flow:
21.67 - 78.02 CFM
Air Pressure:
0.75 - 2.7mm-H2O
Noise:
17.9 - 30.6dBA
Bearing:
Fluid Dynamic Bearing
Power Consumption:
12V DC, 0.23A, 2.76W
Connector:
4-pin PWM
Life:
60,000 hours / 6 Years
COMPATIBLE SOCKET and CPU
Intel:
Intel Socket LGA 1700, 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron
AMD:
AMD Socket AM5, AM4, sTRX4^Note, TR4^Note (Note: Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper
GENERAL
Model Number:
RL-KN36E-B1
Item Dimension (L inchxW inchxH inch)
20 x 8 x 6

Weight
7 lbs

Available Quantity

5

UPC

810074842235

SKU

mingleRL-KN36E-B1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Get high-performance cooling, display a favorite animated GIF or static image, monitor real-time PC performance metrics, see music that's currently playing, stream browser content and more with NZXT CAM software.


2.36 diameter wide-angle LCD display with 640x640 resolution and 60 Hz refresh rate provides a sharp image from any viewing angle

Screen supports the display of custom images, animated GIFs, and CAM system info with adjustable orientation

Powerful Asetek pump provides optimal cooling and up to 2,800 RPM whisper-quiet operation

Includes F140/F120 RGB Core fans

Includes RGB Controller, RGB Fans, & USB Y-Cable

Single breakout cable simplifies installation

Rubber tubing is reinforced with nylon-braided sleeves to prevent leaks

Control custom screen content, pump speed, and zero-noise fan curves with NZXT CAM


Inside the Box

Kraken Elite 280 x1

F 140P Fan x2

Installation Accessories x1

Breakout cable set x1
CAP
Material: Aluminum and plastic
Display Orientation: Software adjustable Default, +90, +180, and -90 Degrees
Display Panel Active Area: 2.36" (60mm) diameter
Display Color: 24-bit true color LCD
Display Resolution: 640 x 640 px
Display Brightness: 690 cd/m²
Display Panel Type: TFT-LCD (Wide Viewing Angle)

WATER BLOCK
Material: Block: Copper / Housing: Plastic

PUMP
Motor Speed: 800 - 2,800 +/- 300RPM
Power: 12V DC, 0.3A

RADIATOR
Material: Aluminum

TUBE
Length: 400mm
Material: Ultra-low Evaporation Rubber with Nylon Braided Sleeve

FAN SPECS
Model: F140P Static Pressure Fan
Quantity: 2
Speed: 500-1,500 +/- 150 RPM
Air Flow: 33.22 - 99.68 CFM
Air Pressure: 0.91 - 2.75mm-H2O
Noise: 19.4 - 32.1dBA
Bearing: Fluid Dynamic Bearing
Power Consumption: 12V DC, 0.28A, 3.36W
Connector: 4-pin PWM
Life: 60,000 hours / 6 Years
COMPATIBLE SOCKET and CPU
Intel: Intel Socket LGA 1700, 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron
AMD: AMD Socket AM5, AM4, sTRX4^note, TR4^note (^Note Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper
Item Dimension (L inchxW inchxH inch)
17 x 9 x 7

Weight
8 lbs

Warranty Information
6 Years

Available Quantity

5

UPC

810074842211

SKU

mingleRL-KN28E-B1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Kraken 280

280mm AIO Liquid Cooler with LCD Display


The Kraken delivers chillingly cool performance, an easy install, and a display screen for system specs or custom images.

Pump features an embedded 1.54 square LCD screen to display real-time system info or custom images

Adjustable screen orientation accommodates pump head position

Powerful Asetek pump provides optimal cooling and up to 2,800 RPM whisper-quiet operation

Includes high-performance PWM fans with fluid dynamic bearings for optimal cooling

Includes F140P/F120P Static Pressure fans

Single breakout cable simplifies installation

Rubber tubing is reinforced with nylon-braided sleeves to prevent leaks

Control custom screen content, pump speed, and zero-noise fan curves with NZXT CAM



Inside the Box

Kraken 280: 1

F140P fan: 2

Installation Accessories: 1

Breakout cable set: 1
CAP
Material:
Aluminum and plastic
Display Orientation:
Software adjustable Default, +90, +180, and -90 Degrees
Display Panel Active Area:
1.54" (39.1mm)
Display Resolution:
240 x 240 px
Display Brightness:
300 cd/m²
Display Panel Type:
Transmissive TFT, 262K color
WATER BLOCK
Material (Block):
Copper
Material (Housing:
Plastic
PUMP
Motor Speed:
800 - 2,800 + 300 RPM
Power:
12VDC, 0.3A
RADIATOR
Material:
Aluminum
TUBE
Length:
400mm
Material:
Ultra-low Evaporation Rubber with Nylon Braided Sleeve
FAN SPECS
Model:
F140P Static Pressure Fan
Quantity:
2
Dimension:
140 x 140 x 26mm
Speed:
500-1,500 +/- 150 RPM
Air Flow:
33.22 - 99.68 CFM
Static Pressure:
0.91 - 2.75mm-H2O
Noise:
19.4 - 32.1dBA
Bearing:
Fluid Dynamic Bearing
Power Consumption:
12V DC, 0.28A, 3.36W
Connector:
4-pin PWM
Life:
60,000 hours / 6 Years
COMPATIBLE SOCKET and CPU
Intel Socket:
Socket LGA 1700, 1200, 115X
Intel: Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron
AMD:
AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper
GENERAL
Model Number:
RL-KN280-B1
Item Dimension (L inchxW inchxH inch)
11 x 9 x 7

Weight
8 lbs

Warranty Information
6 Years

Available Quantity

5

UPC

810074842709

SKU

mingleRL-KN280-B1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Get high-performance cooling, display a favorite animated GIF or static image, monitor real-time PC performance metrics, see music that's currently playing, stream browser content and more with NZXT CAM software.

2.36 diameter wide-angle LCD display with 640x640 resolution and 60 Hz refresh rate provides a sharp image from any viewing angle

Screen supports the display of custom images, animated GIFs, and CAM system info with adjustable orientation

Powerful Asetek pump provides optimal cooling and up to 2,800 RPM whisper-quiet operation

Includes F140P/F120P Static Pressure fans

Single breakout cable simplifies installation

Rubber tubing is reinforced with nylon-braided sleeves to prevent leaks

Control custom screen content, pump speed, and zero-noise fan curves with NZXT CAM


Inside the Box

Kraken Elite 240: 1

F120P fan: 2

Installation Accessories: 1

Breakout cable set: 1
CAP
Material: Aluminum and plastic
Display Orientation: Software adjustable Default, +90, +180, and -90 Degrees
Display Panel Active Area: 2.36" (60mm) diameter
Display Color: 24-bit true color LCD
Display Resolution: 640 x 640 px
Display Brightness: 690 cd/m²
Display Panel Type: TFT-LCD (Wide Viewing Angle)
WATER BLOCK
Material: "Block: Copper Housing: Plastic"
PUMP
Motor Speed: 800 - 2,800 +/- 300 RPM
Power: 12V DC, 0.3A
RADIATOR
Material: Aluminum
TUBE
Length: 400mm
Material: Ultra-low Evaporation Rubber with Nylon Braided Sleeve
FAN
Model: F120P Static Pressure Fan
Quantity: 2
Speed: 500-1,800 +/- 180 RPM
Air Flow: 21.67 - 78.02 CFM
Air Pressure: 0.75 - 2.7mm-H2O
Noise: 17.9 - 30.6dBA
Bearing: Fluid Dynamic Bearing
Power Consumption: 12V DC, 0.23A, 2.76W
Connector: 4-pin PWM
Life: 60,000 hours / 6 Years
COMPATIBLE SOCKET and CPU
Intel: Intel Socket LGA 1700, 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron
AMD: AMD Socket AM5, AM4, sTRX4^Note, TR4^Note (^NoteThreadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper
Item Dimension (L inchxW inchxH inch)
13 x 10 x 6

Weight
6 lbs

Warranty Information
6 years

Available Quantity

5

UPC

810074842198

SKU

mingleRL-KN24E-B1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Details
The Kraken delivers chillingly cool performance, an easy install, and a display screen for system specs or custom images.
Pump features an embedded 1.54 square LCD screen to display real-time system info or custom images
Adjustable screen orientation accommodates pump head position
Powerful Asetek pump provides optimal cooling and up to 2,800 RPM whisper-quiet operation
Includes high-performance PWM fans with fluid dynamic bearings for optimal cooling
Includes F140P/F120P Static Pressure fans
Single breakout cable simplifies installation
Rubber tubing is reinforced with nylon-braided sleeves to prevent leaks
Control custom screen content, pump speed, and zero-noise fan curves with NZXT CAM
Inside the Box
Kraken 240
1
F120P Static Pressure Fan
2
Installation accessories
1
Breakout cable set
1
LCD Display
1.54" square LCD display with 240x240 resolution, 30 Hz refresh rate, and high brightness.
High-Performance Pump
The powerful Asetek pump circulates coolant efficiently and quietly.
Powerful Cooling
Static Pressure Fans with fluid dynamic bearings provide powerful cooling with minimal noise.
CAP
Material:
Aluminum and plastic
Display Orientation:
Software adjustable Default, +90, +180, and -90 Degrees
Display Panel Active Area:
1.54" (39.1mm)
Display Resolution:
240 x 240 px
Display Brightness:
300 cd/m²
Display Panel Type:
Transmissive TFT, 262K color
WATER BLOCK
Dimensions:
Diameter: 74.7mm H: 55.97mm
Material:
Block: Copper, Housing: Plastic
PUMP
Motor Speed:
800 2,800 +/- 300RPM
Power:
12V DC, 0.3A
RADIATOR
Dimensions:
123 x 275 x 30mm
Material:
Aluminum
TUBE
Length:
400mm
Material:
Ultra-low Evaporation Rubber with Nylon Braided Sleeve
FAN(S)
Model:
F120P Static Pressure Fan
Quantity:
2
Dimension:
120 x 120 x 26mm
Speed:
500-1,800 +/- 180 RPM
Air Flow:
21.67 - 78.02 CFM
Air Pressure:
0.75 - 2.7mm-H2O
Noise:
17.9 - 30.6dBA
Bearing:
Fluid Dynamic Bearing
Power Consumption:
12V DC, 0.23A, 2.76W
Connector:
4-pin PWM
Life:
60,000 hours / 6 Years
COMPATIBLE SOCKET and CPU
Intel Socket:
LGA 1700 and 1200/115X
Intel:
Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron
AMD Socket:
AM5, AM4, sTRX4, TR4 (Threadripper bracket not included)
AMD:
Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper
Item Dimension (L"xW"xH")
13 x 10 x 6

Weight
6 lbs

Warranty Information
6 years

Available Quantity

5

UPC

810074842686

SKU

mingleRL-KN240-B1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

This bundle contains three F120 RGB fans and a RGB controller. F120mm fans are high airflow fans that provide the ideal balance between airflow and static pressure. Fan controls and lighting effects are compatible with NZXT CAM.

Designed to dazzle with vibrant RGB lighting effects

Customize RGB lighting through NZXT CAM

Smart frame design with anti-vibration rubber corners dampens noise

The patented Fluid Dynamic Bearing offers a 60,000-hour lifespan

PWM fan for optimized cooling adjustments


Inside the Box

120mm RGB Fan x3

RGB Controller x1

Installation Accessories x1
Material:
Plastic, rubber, PCB
Fan Rated Voltage:
12V DC, 0.18A, 2.16W
LED Quantity:
18
Bearing:
Fluid Dynamic Bearing (FDB)
Fan Connector:
4-pin PWM
COOLING
Speed:
500 - 1,800 +/- 300RPM
Airflow:
13.94 - 50.18 CFM
Static Pressure:
0.75 - 2.7 mm-H2O
Noise:
17.2 - 27.5 dBA
FAN LIFE
Hours:
60,000
Years:
6
RGB CONTROLLER
Material(s):
Plastic, PCB, Magnets
Mounting:
2x 3M Dual Lock
Connections:
1 x USB 2.0 Header, 1 x SATA
Input Connector:
12V DC / 2.6A
Output Channel Voltage:
5V DC
System Requirement:
Requires a USB 2.0 internal connector
RGB Lighting Channels:
3
Lighting channels support:
Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels
Item Dimension (L inchxW inchxH inch)
5 x 4 x 10

Weight
2.00 lb

Warranty Information
2 years

Available Quantity

5

UPC

810074840064

SKU

mingleRF-R12TF-W1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Details
F120 RGB fans provide some flair while keeping things cool. This fan is a high airflow fan that provides ideal airflow for cooling. Fan controls and lighting effects are compatible with NZXT CAM.
Designed to dazzle with vibrant RGB lighting effects
Customize RGB lighting through NZXT CAM
Smart frame design with anti-vibration rubber corners dampens noise
The patented Fluid Dynamic Bearing offers a 60,000-hour lifespan
PWM fan for optimized cooling adjustments
Inside the Box
120mm RGB Fan
1
Installation Accessories
1
KEY SPECS
Material:
Plastic, rubber, PCB
Fan Rated Voltage:
12V DC, 0.18A, 2.16W
LED Quantity:
18
Bearing:
Fluid Dynamic Bearing (FDB)
Fan Connector:
4-pin PWM
COOLING
Speed:
500 - 1,800 +/- 300RPM
Airflow:
13.94 - 50.18 CFM
Static Pressure:
0.75 - 2.7 mm-H2O
Noise:
17.2 - 27.5 dBA
FAN LIFE
Hours:
60,000
Years:
6
GENERAL
Model Number:
RF-R12SF-B1 (Black)
System Requirement:
PC with available NZXT RGB lighting connector and Windows 11/10 operating system. Controller sold separately.
Item Dimension (L"xW"xH")
5 x 2 x 7

Weight
1 lb

Warranty Information
2 years

Available Quantity

5

UPC

815671019936

SKU

mingleRF-R12SF-B1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Details
The F120P fan is designed for high static pressure that forces air through small spaces in your PC allowing more air in small compartments. This fan is designed to cool heat sinks and radiators. Fan controls and lighting effects are compatible with NZXT CAM.
Delivers static pressure for AIO liquid coolers
Seven blades provide powerful airflow
Frame design with anti-vibration rubber corners dampens noise
The Fluid Dynamic Bearing offers a 60,000-hour lifespan
PWM fan for optimized cooling adjustments
Inside the Box
120mm Static Pressure Fan
1
Installation Accessories
1
NZXT BLD
Make it Your Own
From designing your dream build, to selecting the right switch for your mechanical keyboard, NZXT BLD has you covered.
NZXT CAM
Lights. CAM. Action.
NZXT CAM is your go-to software for personalizing the look and performance of your build.
KEY SPECS
Material:
Plastic, Rubber, PCB
Fan Rated Voltage:
12V DC, 0.23A, 2.76W
Bearing:
Fluid Dynamic Bearing (FDB)
Fan Connector:
4-pin PWM
COOLING
Speed:
500 - 1,800 +/- 300RPM
Airflow:
21.67 - 78.02 CFM
Static Pressure:
0.75 - 2.7 mm-H2O
Noise:
17.9 - 30.6 dBA
FAN LIFE
Hours:
60,000
Years:
6
GENERAL
Model Number:
RF-P12SF-W1 (White)
Item Dimension (L"xW"xH")
5 x 2 x 6

Weight
1 lb

Warranty Information
2 years

Available Quantity

5

UPC

810074840118

SKU

mingleRF-P12SF-W1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Details
The RGB Duo Fans strike a balance between bright style and performance with twenty individually addressable RGBs and high static pressure.
Enjoy vibrant RGB lighting from all angles with 20 individually addressable LEDs
Fan blade design deliver the optimal balance between airflow and high static pressure-ideal for use anywhere in a PC
Fluid Dynamic Bearing (FDB) ensures smooth and quiet operation with a long lifespan
Rubber dampeners on the corners reduce vibration noise
PWM fan control means fans cool quickly when needed, but stay quiet at lower loads for maximum efficiency
Mix and match with NZXT F120/F140 RGB fans
Personalize RGB lighting effects and configure fan speeds with NZXT CAM
Inside the Box
140mm RGB Duo Fan
1
Installation Accessories
1
Dual-sided Lighting
20 individually addressable RGB LEDs offer colorful customization and the dual-sided lighting makes any color scheme visible from every angle
Quiet and Cool
PWM fan control means fans cool quickly when needed, but stay quiet at lower loads for maximum efficiency
KEY SPECS
Material:Plastic, rubber, PCB
Fan Rated Voltage:12V DC, 0.26A, 3.12W
LED Quantity:20
Bearing:Fluid Dynamic Bearing (FDB)
Fan Connector:4-pin PWM
COOLING
Speed:500 - 1,800 +/- 300RPM
Airflow:84.75 CFM
Static Pressure:2.72 mm-H2O
Noise:36 dBA
FAN LIFE
Hours:60,000
Years:6
GENERAL
System Requirement:PC with available NZXT RGB lighting connector and Windows 11/10 operating system. Controller sold separately.
Item Dimension (L"xW"xH")
6 x 2 x 8

Weight
1 lb

Warranty Information
2 years

Available Quantity

5

UPC

810074840934

SKU

mingleRF-D14SF-W1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Details
The RGB Duo Fans strike a balance between bright style and performance with twenty individually addressable RGBs and high static pressure.
Enjoy vibrant RGB lighting from all angles with 20 individually addressable LEDs
Fan blade design deliver the optimal balance between airflow and high static pressure-ideal for use anywhere in a PC
Fluid Dynamic Bearing (FDB) ensures smooth and quiet operation with a long lifespan
Rubber dampeners on the corners reduce vibration noise
PWM fan control means fans cool quickly when needed, but stay quiet at lower loads for maximum efficiency
Mix and match with NZXT F120/F140 RGB fans
Personalize RGB lighting effects and configure fan speeds with NZXT CAM
Inside the Box
140mm RGB Duo Fan
1
Installation Accessories
1
Dual-sided Lighting
20 individually addressable RGB LEDs offer colorful customization and the dual-sided lighting makes any color scheme visible from every angle
Quiet and Cool
PWM fan control means fans cool quickly when needed, but stay quiet at lower loads for maximum efficiency
KEY SPECS
Material:Plastic, rubber, PCB
Fan Rated Voltage:12V DC, 0.26A, 3.12W
LED Quantity:20
Bearing:Fluid Dynamic Bearing (FDB)
Fan Connector:4-pin PWM
COOLING
Speed:500 - 1,800 +/- 300RPM
Airflow:84.75 CFM
Static Pressure:2.72 mm-H2O
Noise:36 dBA
FAN LIFE
Hours:60,000
Years:6
GENERAL
System Requirement:PC with available NZXT RGB lighting connector and Windows 11/10 operating system. Controller sold separately.
Item Dimension (L"xW"xH")
6 x 2 x 8

Weight
1 lb

Warranty Information
2 years

Available Quantity

5

UPC

810074840927

SKU

mingleRF-D14SF-B1

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

Illuminate Lian Li s performance LCP fans by adding cool and subtle lighting on the sides without performance compromise. Each side strip features 10 addressable LEDs behind a diffuser for smoothened lighting all around. The side ARGB strips are fully compatible with UNI FAN P28 and the GA II Trinity Performance 360 AIO fans.


EXQUISITE RGB LOOK

Inspired by UNI FAN SLV2 s lighting effects and ALV2 s aluminum strips, the ARGB side strips combine both features and add more ARGB in the center to bring sophisticated RGB looks to the UNI FAN P28 or the GA II Trinity Performance 360 AIO s fans. This helps maintain the high performance of LCP fans while keeping an impressive amount of ARGB lighting in the build.


DAISY-CHAIN DESIGN

Easily daisy-chain 6 ARGB strips with a linker or extension cable to fit seamlessly on LIAN LI performance fans.

Total supported number of strips varies by the number of strips used, the strips brightness, and color. The chart below shows the possible scenarios to give you a better understanding (static white is used as the example because it requires the highest amount of power of all colors).


EXTRA SPACE NEEDED

After adding the side ARGB strip, the width of a one-side installation is 129mm, and 136mm for a two-side installation. Please make sure that there is enough clearance for the side ARGB strips when configuring your build.
PRODUCT NAME
SIDE ARGB Kit for LIAN LI Performance Fan
MODEL
P28ARGB-W
COLOR
White
MATERIAL
PC /ABS/ Aluminum
RATED VOLTAGE
DC 5V
CONNECTOR
3-PIN SM type (include an adaptor to MB 5V ARGB)
Item Dimension (L inchxW inchxH inch)
6 x 4 x 2

Weight
1 lb

Warranty Information
2 Years

Available Quantity

5

UPC

840353044258

SKU

mingleP28ARGB-W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

DUOFACE PRO RGB
The Rule of Two
There are always two sides to every story, and the Duoface Pro RGB is no exception. It offers two distinct front panels that showcase the two sides of its personality: one panel puts the dazzling RGB lighting on display, while the other is optimized for superior airflow. This latest addition to the Duoface series is a true embodiment of flexibility and innovative open-layout design.
Offers two distinct front panels to optimize air intake or showcase your build
The innovative quick-slide dust filter is both highly functional and aesthetically pleasing
The removable top panel and front bracket allow for effortless assembly within the extra-large interior space
Features a built-in RGB fan controller syncing with up to six fans
Supports up to an E-ATX motherboard
Accommodates graphics cards up to 390mm in length
Supports up to nine fans, a 360mm water cooler and CPU coolers up to 190mm in height
A Game of Two Halves
With the new tool-less assembly feature, switching between panels requires minimal effort, allowing you to quickly and easily prioritize between optimizing air intake or showcasing the view of your build on the fly.
Crafted from high-quality 1mm thickness metal and punctuated with 5.0mm diameter perforations, the airflow panel of Duoface Pro RGB delivers exceptional ventilation and generous fresh air intake.
No Style Without Substance
The innovative quick slide dust filter of the Duoface Pro RGB is both highly functional and aesthetically pleasing, with stylish edges that visually sets it apart. Additionally, you can easily slide off the dust filter without removing the front panel, making maintenance a breeze. Why choose between functionality or style when you can have both
Product Name
Duoface Pro RGB
Case Form Factor
Mid Tower
Motherboard Type
Mini ITX / Micro ATX / ATX / CEB / E-ATX
I/O Panel
Type C Gen 2 (Key A 20-pin connector) x 1, USB 3.0 x 2,
USB 2.0 x 1, 4 Pole Headset Audio Jack x 1, RGB Button
3.5" Drive Bay
2
2.5" Drive Bay
2 (2 SSD trays included)
Expansion Slots
7+3
Vertical GPU Support
Yes
Cooling Fan Support
Front
120mm x 3 / 140mm x 2
Top
120mm x 3 / 140mm x 2
PSU Cover
120mm x 2
Rear
120mm x 1 / 140mm x 1
Pre-installed Fans
Front
120mm ARGB fan x 3
Rear
120mm ARGB fan x 1
Speed
1000 RPM
Connector
5V 3 Pin (ARGB) / 3 Pin (Fan)
Maximun Number of Fans
9
Water Cooling Support
Front
360mm / 280mm / 240 mm / 140 mm / 120mm
Top
360mm / 280mm / 240 mm / 140 mm / 120mm
Rear
140 mm / 120mm
Transparent Left Panel
Tempered Glass
Onboard Lighting System
Yes
RGB Sync with M/B
Yes
COUGAR Logo RGB Light
Yes
Max. Graphics Card Length
390 (mm) / 15.4 (in)
Max. CPU Cooler Height
190 (mm) / 7.5 (in)
Max. PSU Length
200 (mm) / 7.9 (in)
Item Dimension (L"xW"xH")
13 x 23 x 23

Weight
50 lbs

Warranty Information
1 year

Available Quantity

5

UPC

192554005584

SKU

mingleDUOFACE RGB PRO BLACK

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

CORSAIR AF120 RGB ELITE High-Performance 120mm PWM fans deliver PWM-controlled fan speeds from 550 RPM up to 2,100 RPM for powerful cooling, quiet operation, and brilliant RGB lighting.



KEEP YOUR SYSTEM COOL

The ideal cooling fans for your PC with optimal airflow at low to medium speeds.

With up to 65.57 CFM of airflow at peak 2,100 RPM, AF RGB ELITE Series fans deliver the perfect balance between low noise, strong static pressure, and high airflow without compromising performance.



ULTRA QUIET OPERATION

A fluid dynamic bearing utilizes lubricant to reduce friction, resulting in exceptional durability and minimal noise.

When your computer is idling, you can rely on Zero RPM mode to turn off the fans and completely eliminate fan noise.



BRILLIANT RGB LED LIGHTING

Eight individually addressable RGB LEDs provide a brilliant backdrop in your PC build.*

*Requires iCUE lighting controller and CORSAIR iCUE software.
iCUE Lighting Node CORE controller included with AF RGB ELITE multi-fan kits.



CORSAIR AIRGUIDE TECHNOLOGY

Utilizes anti-vortex vanes to channel concentrated airflow and improve cooling, whether used as intake, exhaust, or mounted to a liquid cooling radiator or heatsink.
Fan Airflow
13.8 - 65.57 CFM
Flow Type
STATIC PRESSURE
CORSAIR LINK compatibility
Yes
LINK Compatibility
RGB
Fan Static Pressure
0.17 - 2.68 mm-H2O
Speed
550 - 2100 RPM +/-10%
Sound Level
5 - 34.1 dBA
PWM Control
Yes
Power Draw
0.38A
Package Quantity
3
LED Color
RGB
Fan Size
120mm x 25mm
Package Contents
3x CORSAIR AF120 RGB ELITE Fan
12x Fan Mounting Screws
1x CORSAIR Lighting Node CORE
Item Dimension (L inchxW inchxH inch)
6 x 6 x 4

Weight
2 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840006662303

SKU

mingleCO-9050158-WW

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

The CORSAIR iCUE SP120 RGB ELITE Performance Triple Fan Kit boasts eight bright, individually addressable RGB LEDs on each fan, for a vivid RGB lighting upgrade for any PC.



CORSAIR AIRGUIDE TECHNOLOGY

SP RGB Elite series fans utilize anti-vortex vanes to direct airflow and concentrate cooling, improving cooling whether used as intake, exhaust, or mounted to a liquid cooling radiator or heatsink.


MESMERIZING RGB LIGHTING

Eight Individually Addressable RGB LEDs line the central fan hub and diffuse outwards through the semi-opaque fan blades for a subtle and elegant glowing effect.


YOUR SETUP AT YOUR COMMAND

With the included* iCUE Lighting Node CORE you can create vivid lighting effects, bringing your system to life with dynamic RGB lighting using our powerful iCUE software.

* Lighting Node Core is included on multi-packs only, but can be purchased separately


LOW-NOISE, HIGH-PERFORMANCE

With noise levels as low as 7 dBA, the SP RGB ELITE s translucent fan blades provide ample airflow while still letting your RGB lighting shine through.
Fan Airflow
16.91 - 47.73 CFM
Fan Model
SP Series
Flow Type
STATIC PRESSURE
CORSAIR LINK compatibility
Yes
LINK Compatibility
RGB
Fan Static Pressure
0.28 - 1.46mm-H2O
Speed
1500 +/- 10% RPM
Sound Level
5 - 22.6 dBA
PWM Control
Yes
Power Draw
0.30A
Package Quantity
3
Operating Voltage
6V - 13.2V
LED Color
RGB
Fan Size
120mm x 25mm
Bearing Type
Hydraulic
Package Contents
3x CORSAIR SP120 RGB ELITE Fans
12x Mounting Screws
1x CORSAIR Lighting Node CORE
1x Quick Start Guide
Item Dimension (L inchxW inchxH inch)
7 x 6 x 5

Weight
2 lbs

Warranty Information
2 Years

Available Quantity

5

UPC

840006637776

SKU

mingleCO-9050137-WW

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 140
MODEL
14TLLCD1W
COLOR
White
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
144 X 140 X 28 (mm)
FAN SPEED
0, 400-1600 RPM
MAX. AIR PRESSURE
3.5 mmH2O (Maximum)
MAX. AIRFLOW
68.1 CFM (Maximum)
ACOUSTIC NOISE
28.5 dB(A) Max
INPUT POWER
6.72W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
7 x 3 x 8

Weight
2 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045248

SKU

mingle14TLLCD1W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 140
MODEL
14TLLCD1B
COLOR
Black
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
144 X 140 X 28 (mm)
FAN SPEED
0, 400-1600 RPM
MAX. AIR PRESSURE
3.5 mmH2O (Maximum)
MAX. AIRFLOW
68.1 CFM (Maximum)
ACOUSTIC NOISE
28.5 dB(A) Max
INPUT POWER
6.72W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
7 x 3 x 8

Weight
2 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045231

SKU

mingle14TLLCD1B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

NEXT GENERATION OF UNI FAN

Building on the design success of the UNI FAN series, the UNI FAN TL series takes clutter-free setups to the next level.



Durable Daisy-Chain Solution

Experience a hassle-free setup with the slide-in daisy-chaining mechanism, securely holding the fans in place and ensuring a snug fit for easy configuration.



Seamless Connection

Featuring both male and female ends, the cable can be connected to both sides of the fan, providing enhanced flexibility and ease of installation.



Well-Adapted for all Configuration

Besides the removing interlocking key, the TL fans includes connection covers the exposed connections at the end to prevent short circuits while improving compatibility.



10 fans in a Row and up to 16 fans

Enable connection of up to 10 fans to a controller port using the extension cable, which offers ability to create up to 4 clusters in a chain, with each cluster support a maximum of 4 fans for individual customization of fan RPM and lighting, allowing a truly personalized build setup such as having 3 fans on the top, 3 on the side, 3 on the bottom, and 1 on the rear.



Power till the end

Offering an extra power adapter in triple pack to connect to SATA for consistent fan speed and LED color throughout.



ENGINEERED MOTOR, STURDY STRUCTURE

UNI FAN TL is engineered for high performance with minimal friction and vibration, ensuring quiet operation even at high speeds.
PRODUCT NAME
UNI FAN TL 140

MODEL
14TL1W

COLOR
White

NUMBER OF FANS
1

CONTROLLER
No

CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
Extension Cable x 1 (P-P)

FAN SPEED
0, 200-1800 RPM

MAX. AIR PRESSURE
2.34 mmH2O (Maximum)

MAX. AIRFLOW
103.9 CFM (Maximum)

ACOUSTIC NOISE
29 dB(A) Max

INPUT POWER
4.6W

MATERIAL
PA66 / LCP

RATED VOLTAGE
DC 12V (FAN) and 5V (LED)

BEARING TYPE
Fluid Dynamic Bearing (FDB)

OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L inchxW inchxH inch)
7 x 2 x 8

Weight
1 lb

Warranty Information
3 Years

Available Quantity

5

UPC

840353045224

SKU

mingle14TL1W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

NEXT GENERATION OF UNI FAN

Building on the design success of the UNI FAN series, the UNI FAN TL series takes clutter-free setups to the next level.



Durable Daisy-Chain Solution

Experience a hassle-free setup with the slide-in daisy-chaining mechanism, securely holding the fans in place and ensuring a snug fit for easy configuration.



Seamless Connection

Featuring both male and female ends, the cable can be connected to both sides of the fan, providing enhanced flexibility and ease of installation.



Well-Adapted for all Configuration

Besides the removing interlocking key, the TL fans includes connection covers the exposed connections at the end to prevent short circuits while improving compatibility.



10 fans in a Row and up to 16 fans

Enable connection of up to 10 fans to a controller port using the extension cable, which offers ability to create up to 4 clusters in a chain, with each cluster support a maximum of 4 fans for individual customization of fan RPM and lighting, allowing a truly personalized build setup such as having 3 fans on the top, 3 on the side, 3 on the bottom, and 1 on the rear.



Power till the end

Offering an extra power adapter in triple pack to connect to SATA for consistent fan speed and LED color throughout.



ENGINEERED MOTOR, STURDY STRUCTURE

UNI FAN TL is engineered for high performance with minimal friction and vibration, ensuring quiet operation even at high speeds.
PRODUCT NAME
UNI FAN TL 140

MODEL
14TL1B

COLOR
Black

NUMBER OF FANS
1

CONTROLLER
No

CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
Extension Cable x 1 (P-P)

FAN SPEED
0, 200-1800 RPM

MAX. AIR PRESSURE
2.34 mmH2O (Maximum)

MAX. AIRFLOW
103.9 CFM (Maximum)

ACOUSTIC NOISE
29 dB(A) Max

INPUT POWER
4.6W

MATERIAL
PA66 / LCP

RATED VOLTAGE
DC 12V (FAN) and 5V (LED)

BEARING TYPE
Fluid Dynamic Bearing (FDB)

OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L inchxW inchxH inch)
7 x 2 x 8

Weight
1 lb

Warranty Information
3 Years

Available Quantity

5

UPC

840353045217

SKU

mingle14TL1B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 140 Reverse Blade
MODEL
14RTLLCD1W
COLOR
White
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
144 X 140 X 28 (mm)
FAN SPEED
0, 350-1600 RPM
MAX. AIR PRESSURE
3.1 mmH2O (Maximum)
MAX. AIRFLOW
64 CFM (Maximum)
ACOUSTIC NOISE
29.4 dB(A) Max
INPUT POWER
6.72W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
7 x 3 x 8

Weight
2 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045286

SKU

mingle14RTLLCD1W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 140 Reverse Blade
MODEL
14RTLLCD1B
COLOR
Black
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
144 X 140 X 28 (mm)
FAN SPEED
0, 350-1600 RPM
MAX. AIR PRESSURE
3.1 mmH2O (Maximum)
MAX. AIRFLOW
64 CFM (Maximum)
ACOUSTIC NOISE
29.4 dB(A) Max
INPUT POWER
6.72W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
7 x 3 x 8

Weight
2 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045279

SKU

mingle14RTLLCD1B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

NEXT GENERATION OF UNI FAN

Building on the design success of the UNI FAN series, the UNI FAN TL series takes clutter-free setups to the next level.



Durable Daisy-Chain Solution

Experience a hassle-free setup with the slide-in daisy-chaining mechanism, securely holding the fans in place and ensuring a snug fit for easy configuration.



Seamless Connection

Featuring both male and female ends, the cable can be connected to both sides of the fan, providing enhanced flexibility and ease of installation.



Well-Adapted for all Configuration

Besides the removing interlocking key, the TL fans includes connection covers the exposed connections at the end to prevent short circuits while improving compatibility.



10 fans in a Row and up to 16 fans

Enable connection of up to 10 fans to a controller port using the extension cable, which offers ability to create up to 4 clusters in a chain, with each cluster support a maximum of 4 fans for individual customization of fan RPM and lighting, allowing a truly personalized build setup such as having 3 fans on the top, 3 on the side, 3 on the bottom, and 1 on the rear.



Power till the end

Offering an extra power adapter in triple pack to connect to SATA for consistent fan speed and LED color throughout.



ENGINEERED MOTOR, STURDY STRUCTURE

UNI FAN TL is engineered for high performance with minimal friction and vibration, ensuring quiet operation even at high speeds.
PRODUCT NAME
UNI FAN TL 140 Reverse Blade

MODEL
14RTL1W

COLOR
White

NUMBER OF FANS
1

CONTROLLER
No

CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
Extension Cable x 1 (P-P)

FAN SPEED
0, 200-1800 RPM

MAX. AIR PRESSURE
2.27 mmH2O (Maximum)

MAX. AIRFLOW
101.6 CFM (Maximum)

ACOUSTIC NOISE
31 dB(A) Max

INPUT POWER
4.6W

MATERIAL
PA66 / LCP

RATED VOLTAGE
DC 12V (FAN) and 5V (LED)

BEARING TYPE
Fluid Dynamic Bearing (FDB)

OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L inchxW inchxH inch)
7 x 2 x 8

Weight
1 lb

Warranty Information
3 Years

Available Quantity

5

UPC

840353045262

SKU

mingle14RTL1W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

NEXT GENERATION OF UNI FAN

Building on the design success of the UNI FAN series, the UNI FAN TL series takes clutter-free setups to the next level.



Durable Daisy-Chain Solution

Experience a hassle-free setup with the slide-in daisy-chaining mechanism, securely holding the fans in place and ensuring a snug fit for easy configuration.



Seamless Connection

Featuring both male and female ends, the cable can be connected to both sides of the fan, providing enhanced flexibility and ease of installation.



Well-Adapted for all Configuration

Besides the removing interlocking key, the TL fans includes connection covers the exposed connections at the end to prevent short circuits while improving compatibility.



10 fans in a Row and up to 16 fans

Enable connection of up to 10 fans to a controller port using the extension cable, which offers ability to create up to 4 clusters in a chain, with each cluster support a maximum of 4 fans for individual customization of fan RPM and lighting, allowing a truly personalized build setup such as having 3 fans on the top, 3 on the side, 3 on the bottom, and 1 on the rear.



Power till the end

Offering an extra power adapter in triple pack to connect to SATA for consistent fan speed and LED color throughout.



ENGINEERED MOTOR, STURDY STRUCTURE

UNI FAN TL is engineered for high performance with minimal friction and vibration, ensuring quiet operation even at high speeds.
PRODUCT NAME
UNI FAN TL 140 Reverse Blade

MODEL
14RTL1B

COLOR
Black

NUMBER OF FANS
1

CONTROLLER
No

CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
Extension Cable x 1 (P-P)

FAN SPEED
0, 200-1800 RPM

MAX. AIR PRESSURE
2.27 mmH2O (Maximum)

MAX. AIRFLOW
101.6 CFM (Maximum)

ACOUSTIC NOISE
31 dB(A) Max

INPUT POWER
4.6W

MATERIAL
PA66 / LCP

RATED VOLTAGE
DC 12V (FAN) and 5V (LED)

BEARING TYPE
Fluid Dynamic Bearing (FDB)

OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L inchxW inchxH inch)
7 x 2 x 8

Weight
1 lb

Warranty Information
3 Years

Available Quantity

5

UPC

840353045255

SKU

mingle14RTL1B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 120
MODEL
12TLLCD3W
COLOR
White
NUMBER OF FANS
3
CONTROLLER
Yes
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
124 x 120 x 28 mm
FAN SPEED
0, 350-1900 RPM
MAX. AIR PRESSURE
2.9 mmH2O (Maximum)
MAX. AIRFLOW
62 CFM (Maximum)
ACOUSTIC NOISE
27 dB(A) Max
INPUT POWER
7.08W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
7 x 6 x 7

Weight
3 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045149

SKU

mingle12TLLCD3W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 120
MODEL
12TLLCD3B
COLOR
Black
NUMBER OF FANS
3
CONTROLLER
Yes
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
124 x 120 x 28 mm
FAN SPEED
0, 350-1900 RPM
MAX. AIR PRESSURE
2.9 mmH2O (Maximum)
MAX. AIRFLOW
62 CFM (Maximum)
ACOUSTIC NOISE
27 dB(A) Max
INPUT POWER
7.08W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
7 x 6 x 7

Weight
3 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045132

SKU

mingle12TLLCD3B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 120
MODEL
12TLLCD1W
COLOR
White
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
124 x 120 x 28 mm
FAN SPEED
0, 350-1900 RPM
MAX. AIR PRESSURE
2.9 mmH2O (Maximum)
MAX. AIRFLOW
62 CFM (Maximum)
ACOUSTIC NOISE
27 dB(A) Max
INPUT POWER
7.08W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
6 x 3 x 7

Weight
2 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353044968

SKU

mingle12TLLCD1W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 120
MODEL
12TLLCD1B
COLOR
Black
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
124 x 120 x 28 mm
FAN SPEED
0, 350-1900 RPM
MAX. AIR PRESSURE
2.9 mmH2O (Maximum)
MAX. AIRFLOW
62 CFM (Maximum)
ACOUSTIC NOISE
27 dB(A) Max
INPUT POWER
7.08W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
6 x 3 x 7

Weight
2 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353044951

SKU

mingle12TLLCD1B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

NEXT GENERATION OF UNI FAN

Building on the design success of the UNI FAN series, the UNI FAN TL series takes clutter-free setups to the next level.



Durable Daisy-Chain Solution

Experience a hassle-free setup with the slide-in daisy-chaining mechanism, securely holding the fans in place and ensuring a snug fit for easy configuration.



Seamless Connection

Featuring both male and female ends, the cable can be connected to both sides of the fan, providing enhanced flexibility and ease of installation.



Well-Adapted for all Configuration

Besides the removing interlocking key, the TL fans includes connection covers the exposed connections at the end to prevent short circuits while improving compatibility.



10 fans in a Row and up to 16 fans

Enable connection of up to 10 fans to a controller port using the extension cable, which offers ability to create up to 4 clusters in a chain, with each cluster support a maximum of 4 fans for individual customization of fan RPM and lighting, allowing a truly personalized build setup such as having 3 fans on the top, 3 on the side, 3 on the bottom, and 1 on the rear.



Power till the end

Offering an extra power adapter in triple pack to connect to SATA for consistent fan speed and LED color throughout.



ENGINEERED MOTOR, STURDY STRUCTURE

UNI FAN TL is engineered for high performance with minimal friction and vibration, ensuring quiet operation even at high speeds.
PRODUCT NAME
UNI FAN TL 120
MODEL
12TL3W
COLOR
White
NUMBER OF FANS
3
CONTROLLER
Yes
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
Extension Cable x 1 (P-P)
Power Adapter Cable x 1 (P-SA)
FAN SPEED
0, 200-2600 RPM
MAX. AIR PRESSURE
3.97 mmH2O (Maximum)
MAX. AIRFLOW
90.1 CFM (Maximum)
ACOUSTIC NOISE
33 dB(A) Max
INPUT POWER
5.8W
MATERIAL
PA66 / LCP
MATERIAL
PA66 / LCP

RATED VOLTAGE
DC 12V (FAN) and 5V (LED)

BEARING TYPE
Fluid Dynamic Bearing (FDB)

OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L inchxW inchxH inch)
7 x 5 x 7

Weight
2.13 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045125

SKU

mingle12TL3W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

NEXT GENERATION OF UNI FAN

Building on the design success of the UNI FAN series, the UNI FAN TL series takes clutter-free setups to the next level.



Durable Daisy-Chain Solution

Experience a hassle-free setup with the slide-in daisy-chaining mechanism, securely holding the fans in place and ensuring a snug fit for easy configuration.



Seamless Connection

Featuring both male and female ends, the cable can be connected to both sides of the fan, providing enhanced flexibility and ease of installation.



Well-Adapted for all Configuration

Besides the removing interlocking key, the TL fans includes connection covers the exposed connections at the end to prevent short circuits while improving compatibility.



10 fans in a Row and up to 16 fans

Enable connection of up to 10 fans to a controller port using the extension cable, which offers ability to create up to 4 clusters in a chain, with each cluster support a maximum of 4 fans for individual customization of fan RPM and lighting, allowing a truly personalized build setup such as having 3 fans on the top, 3 on the side, 3 on the bottom, and 1 on the rear.



Power till the end

Offering an extra power adapter in triple pack to connect to SATA for consistent fan speed and LED color throughout.



ENGINEERED MOTOR, STURDY STRUCTURE

UNI FAN TL is engineered for high performance with minimal friction and vibration, ensuring quiet operation even at high speeds.
PRODUCT NAME
UNI FAN TL 120

MODEL
12TL1W

COLOR
White

NUMBER OF FANS
1

CONTROLLER
No

CONNECTOR TYPE
UNI FAN Controller Cable x 1
(P-7P)
Extension Cable x 1 (P-P)

FAN SPEED
0, 200-2600 RPM

MAX. AIR PRESSURE
3.97 mmH2O (Maximum)

MAX. AIRFLOW
90.1 CFM (Maximum)

ACOUSTIC NOISE
33 dB(A) Max

INPUT POWER
5.8W

MATERIAL
PA66 / LCP

RATED VOLTAGE
DC 12V (FAN) and 5V (LED)

BEARING TYPE
Fluid Dynamic Bearing (FDB)

OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L inchxW inchxH inch)
6 x 2 x 7

Weight
1 lb

Warranty Information
3 Years

Available Quantity

5

UPC

840353044944

SKU

mingle12TL1W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

NEXT GENERATION OF UNI FAN

Building on the design success of the UNI FAN series, the UNI FAN TL series takes clutter-free setups to the next level.



Durable Daisy-Chain Solution

Experience a hassle-free setup with the slide-in daisy-chaining mechanism, securely holding the fans in place and ensuring a snug fit for easy configuration.



Seamless Connection

Featuring both male and female ends, the cable can be connected to both sides of the fan, providing enhanced flexibility and ease of installation.



Well-Adapted for all Configuration

Besides the removing interlocking key, the TL fans includes connection covers the exposed connections at the end to prevent short circuits while improving compatibility.



10 fans in a Row and up to 16 fans

Enable connection of up to 10 fans to a controller port using the extension cable, which offers ability to create up to 4 clusters in a chain, with each cluster support a maximum of 4 fans for individual customization of fan RPM and lighting, allowing a truly personalized build setup such as having 3 fans on the top, 3 on the side, 3 on the bottom, and 1 on the rear.



Power till the end

Offering an extra power adapter in triple pack to connect to SATA for consistent fan speed and LED color throughout.



ENGINEERED MOTOR, STURDY STRUCTURE

UNI FAN TL is engineered for high performance with minimal friction and vibration, ensuring quiet operation even at high speeds.
PRODUCT NAME
UNI FAN TL 120
MODEL
12TL1B
COLOR
Black
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
UNI FAN Controller Cable x 1
(P-7P)
Extension Cable x 1 (P-P)
FAN SPEED
0, 200-2600 RPM
MAX. AIR PRESSURE
3.97 mmH2O (Maximum)
MAX. AIRFLOW
90.1 CFM (Maximum)
ACOUSTIC NOISE
33 dB(A) Max
INPUT POWER
5.8W
MATERIAL
PA66 / LCP

RATED VOLTAGE
DC 12V (FAN) and 5V (LED)

BEARING TYPE
Fluid Dynamic Bearing (FDB)

OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L inchxW inchxH inch)
6 x 2 x 7

Weight
1 lb

Warranty Information
3 Years

Available Quantity

5

UPC

840353044937

SKU

mingle12TL1B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 120 Reverse Blade
MODEL
12RTLLCD3W
COLOR
White
NUMBER OF FANS
3
CONTROLLER
Yes
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
124 x 120 x 28 mm
FAN SPEED
0, 350-1900 RPM
MAX. AIR PRESSURE
2.83 mmH2O (Maximum)
MAX. AIRFLOW
54.3 CFM (Maximum)
ACOUSTIC NOISE
31 dB(A) Max
INPUT POWER
7.08W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
7 x 6 x 7

Weight
3 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045187

SKU

mingle12RTLLCD3W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 120 Reverse Blade
MODEL
12RTLLCD3B
COLOR
Black
NUMBER OF FANS
3
CONTROLLER
Yes
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
124 x 120 x 28 mm
FAN SPEED
0, 350-1900 RPM
MAX. AIR PRESSURE
2.83 mmH2O (Maximum)
MAX. AIRFLOW
54.3 CFM (Maximum)
ACOUSTIC NOISE
31 dB(A) Max
INPUT POWER
7.08W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
7 x 6 x 7

Weight
3 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045170

SKU

mingle12RTLLCD3B

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

UNI FAN TL LCD
1.6 LCD Screen with 400400 resolution.
Supports GIF, MP4, JPG, and PNG files.
Suitable as a PC case with airflow and noise optimization.
Comes with Lian Li exclusive flow-through animations through L-Connect 3.
FDB bearing that provides stability, durability, and longevity.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
LED lighting and fan speed controller shared with UNIFAN TL.
Complete software control with L-Connect 3.
AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.
Meet all kinds of configuration needs with our full lineup.
Note: Do not mount the fan with the LCD facing inward, as it may result in damage to the screen
EMPOWER WITH CUSTOMIZABLE DISPLAY
The worlds 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.
PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.
PRODUCT NAME
UNI FAN TL LCD 120 Reverse Blade
MODEL
12RTLLCD1W
COLOR
White
NUMBER OF FANS
1
CONTROLLER
No
CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
FAN DIMENSION
124 x 120 x 28 mm
FAN SPEED
0, 350-1900 RPM
MAX. AIR PRESSURE
2.83 mmH2O (Maximum)
MAX. AIRFLOW
54.3 CFM (Maximum)
ACOUSTIC NOISE
31 dB(A) Max
INPUT POWER
7.08W
MATERIAL
PA66 / PBT
RATED VOLTAGE
DC 12V (FAN) and 5V (LED)
BEARING TYPE
Fluid Dynamic Bearing (FDB)
OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L"xW"xH")
6 x 3 x 7

Weight
2 lbs

Warranty Information
3 Years

Available Quantity

5

UPC

840353045002

SKU

mingle12RTLLCD1W

Rebate

10% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Add or Remove from Cart

Product Description

NEXT GENERATION OF UNI FAN

Building on the design success of the UNI FAN series, the UNI FAN TL series takes clutter-free setups to the next level.



Durable Daisy-Chain Solution

Experience a hassle-free setup with the slide-in daisy-chaining mechanism, securely holding the fans in place and ensuring a snug fit for easy configuration.



Seamless Connection

Featuring both male and female ends, the cable can be connected to both sides of the fan, providing enhanced flexibility and ease of installation.



Well-Adapted for all Configuration

Besides the removing interlocking key, the TL fans includes connection covers the exposed connections at the end to prevent short circuits while improving compatibility.



10 fans in a Row and up to 16 fans

Enable connection of up to 10 fans to a controller port using the extension cable, which offers ability to create up to 4 clusters in a chain, with each cluster support a maximum of 4 fans for individual customization of fan RPM and lighting, allowing a truly personalized build setup such as having 3 fans on the top, 3 on the side, 3 on the bottom, and 1 on the rear.



Power till the end

Offering an extra power adapter in triple pack to connect to SATA for consistent fan speed and LED color throughout.



ENGINEERED MOTOR, STURDY STRUCTURE

UNI FAN TL is engineered for high performance with minimal friction and vibration, ensuring quiet operation even at high speeds.
PRODUCT NAME
UNI FAN TL 120 Reverse Blade

MODEL
12RTL1W

COLOR
White

NUMBER OF FANS
1

CONTROLLER
No

CONNECTOR TYPE
UNI FAN Controller Cable x 1 (P-7P)
Extension Cable x 1 (P-P)

FAN SPEED
0, 200-2300 RPM

MAX. AIR PRESSURE
2.66 mmH2O (Maximum)

MAX. AIRFLOW
83.4 CFM (Maximum)

ACOUSTIC NOISE
34 dB(A) Max

INPUT POWER
4.5W

MATERIAL
PA66 / LCP

RATED VOLTAGE
DC 12V (FAN) and 5V (LED)

BEARING TYPE
Fluid Dynamic Bearing (FDB)

OPERATE VOLTAGE
DC12V and 5V
Item Dimension (L inchxW inchxH inch)
6 x 2 x 7

Weight
1 lb

Warranty Information
3 Years

Available Quantity

5

UPC

840353044982

SKU

mingle12RTL1W
