Product Description

Specifications

• Mfr Part Number: TUF GAMING B460-PRO (WI-FI)
• CPU:
  • Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors
  • Supports Intel 14 nm CPU
  • Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
• Chipset: Intel B460
• Memory:
  • 4 x DIMM, Max. 128GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  • Dual Channel Memory Architecture
  • Supports Intel Extreme Memory Profile (XMP)
  • OptiMem
• Graphic:
  • Integrated Graphics Processor

  • 1 x DisplayPort 1.4

  • 1 x HDMI 1.4b

• Multi-GPU Support: Supports AMD 2-Way CrossFireX Technology
• Expansion Slots:
  • Intel 10th Gen Processors
    - 1 x PCIe 3.0 x16 (x16 mode)
  • Intel B460 Chipset
    - 1 x PCIe 3.0 x16 (x4 mode)
    - 3 x PCIe 3.0 x1
• Storage:
  • Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
  • Intel B460 Chipset:
    - 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
    - 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
    - 6 x SATA 6Gb/s port(s)
    - Support Raid 0, 1, 5, 10
    - Intel Rapid Storage Technology supports
    - Intel Optane Memory Ready
• LAN: Intel I219-V 1Gb Ethernet
• Wireless Data Network:
  • Intel Wi-Fi 6 AX200
  • 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO
  • Supports up to 2.4Gbps max data rate
  • Supports dual band frequency 2.4/5 GHz
  • Supports channel bandwidth: HT20/HT40/HT80/HT160
  • Supports PCIe interface
• Bluetooth: Bluetooth v5.1
• Audio:
  • Realtek ALC S1200A 8-Channel High Definition Audio CODEC
    - Supports : Jack-detection, Multi-recording, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
  • Audio Feature :
    - Exclusive DTS Custom for GAMING Headsets.
    - Audio cover
    - Audio Shielding
    - Dedicated audio PCB layers
    - Premium Japanese audio capacitors
• USB Ports:
  • Rear USB Port ( Total 6 )
    - 2 x USB 3.2 Gen 2 port(s)(2 x Type-A)
    - 4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
  • Front USB Port ( Total 6 )
    - 2 x USB 3.2 Gen 1 port(s)
    - 4 x USB 2.0 port(s)
• Software Features:
  • ASUS Exclusive Software
  • Armoury Crate
    - Aura Sync
  • AI Suite 3

    - Performance And Power Saving Utility
  • Digi+ VRM
  • EPU
  • Fan Xpert 4
    - EZ update
    - PC Cleaner
    - System Information
  • AI Charger
  • ASUS Turbo LAN
  • DTS Custom for GAMING Headsets
  • Norton Anti-virus software (Free Trial for 60 days)
  • DAEMON Tools
  • Google Chrome Browser & Google Toolbar
  • TUF GAMING CPU-Z
  • WinRAR
  • UEFI BIOS
  • ASUS EZ DIY
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    - ASUS UEFI BIOS EZ Mode
• ASUS Special Features:
  • ASUS TUF PROTECTION
    - ASUS DIGI+ VRM
    - ASUS Enhanced DRAM Overcurrent Protection
    - ASUS ESD Guards
    - ASUS LANGuard
    - ASUS Overvoltage Protection
    - ASUS SafeSlot Core+
    - ASUS Stainless-Steel Back I/O
  • ASUS Q-Design :
    - ASUS Q-DIMM
    - ASUS Q-Slot
    - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
  • ASUS Thermal Solution:
    - Aluminum M.2 heatsink
    - Aluminum heatsink design
  • ASUS EZ DIY
    - Box Headers
  • AURA Sync
    - Addressable Gen 2 RGB header
    - Standard RGB headers
• Back I/O Ports:
  • 1 x PS/2 keyboard/mouse combo port(s)
  • 1 x DisplayPort
  • 1 x HDMI
  • 1 x LAN (RJ45) port(s)
  • 2 x USB 3.2 Gen 2 Type-A
  • 4 x USB 3.2 Gen 1 Type-A
  • 3 x Audio jack(s)
  • 1 x ASUS Wi-Fi Module
• Internal I/O Ports:
  • 1 x CPU Fan connector(s)
  • 1 x CPU OPT Fan connector(s)
  • 2 x Chassis Fan connector(s)
  • 1 x AIO_PUMP connector
  • 2 x Aura RGB Strip Headers
  • 1 x Addressable Gen 2 header(s)
  • 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
  • 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  • 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  • 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
  • 6 x SATA 6Gb/s connector(s)
  • 1 x 24-pin EATX Power connector(s)
  • 1 x 8-pin EATX 12V Power connectors
  • 1 x Front panel audio connector(s) (AAFP)
  • 1 x Clear CMOS jumper(s)
  • 1 x System panel connector
  • 1 x COM port header
• Accessories:
  • User's manual
  • I/O Shield
  • 2 x SATA 6Gb/s cable(s)
  • 1 x Supporting DVD
  • 1 x TUF Gaming Sticker
  • 1 x TUF Certification card(s)
  • 1 x Wi-Fi moving antenna
  • 1 x M.2 SSD screw package(s)
  • 1 x M.2 Rubber Package(s)
• BIOS: 128 Mb Flash ROM, UEFI AMI BIOS
• Manageability: WOL by PME, PXE
• Operating System: Windows 10 64-bit
• Form Factor:
  • ATX Form Factor
  • 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.

Note

Currently out of stock

Available Quantity

0

UPC

192876719763

SKU

mingleTUF GAMING B460-PRO (WI-FI)

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: PRIME Z490M-PLUS
• CPU:
  • Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors
  • Supports Intel 14 nm CPU
  • Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
• Chipset: Intel Z490
• Memory:
  • 4 x DIMM, Max. 128GB, DDR4 4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  • Dual Channel Memory Architecture
  • Supports Intel Extreme Memory Profile (XMP)
  • OptiMem
• Graphic:
  • Integrated Graphics Processor
  • 1 x DisplayPort 1.4
  • 1 x HDMI 1.4b
  • 1 x DVI-D
• Multi-GPU Support:  Supports AMD 2-Way CrossFireX Technology
• Expansion Slots:
  • Intel 10th Gen Processors
    - 1 x PCIe 3.0 x16 (x16 mode)

  • Intel Z490 Chipset
    - 1 x PCIe 3.0 x16 (x4 mode)
    - 2 x PCIe 3.0 x1
• Storage:
  • Total supports 2 x M.2 slots and 5 x SATA 6Gb/s ports
  • Intel Z490 Chipset:
    - 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
    - 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
    - 5 x SATA 6Gb/s port(s)

    - Support Raid 0, 1, 5, 10
    - Intel Rapid Storage Technology supports
    - Intel Optane Memory Ready

• LAN: Intel I219-V 1Gb Ethernet
• Audio:
  • Realtek ALC887 8-Channel High Definition Audio CODEC
    - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
  • Audio Feature :
    - LED-illuminated design
    - Audio Shielding
    - Dedicated audio PCB layers
    - Premium Japanese audio capacitors
• USB Ports:
  • Rear USB Port ( Total 6 )
    - 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C)
    - 2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
    - 2 x USB 2.0 port(s)(2 x Type-A)
  • Front USB Port ( Total 8 )
    - 4 x USB 3.2 Gen 1 port(s)
    - 4 x USB 2.0 port(s)
• Software Features:
  • ASUS Exclusive Software
  • Armoury Crate
  • AI Suite 3
    - Performance And Power Saving Utility
  • EPU
  • Digi+ VRM
  • Fan Xpert 4
    - EZ update
  • AI Charger
  • WinRAR
  • UEFI BIOS
  • ASUS EZ DIY

    - ASUS CrashFree BIOS 3

    - ASUS EZ Flash 3

    - ASUS UEFI BIOS EZ Mode
• ASUS Special Features:
  • ASUS 5X PROTECTION III

    - ASUS DIGI+ VRM (- Digital power design with Dr. MOS)

    - ASUS LANGuard

    - ASUS Overvoltage Protection

    - ASUS SafeSlot Core+

    - ASUS Stainless-Steel Back I/O
  • ASUS Q-Design
    - ASUS Q-DIMM
    - ASUS Q-Slot
  • ASUS Thermal Solution
    - Aluminum heatsink design
  • ASUS EZ DIY

    - Procool
• Back I/O Ports:
  • 1 x PS/2 keyboard/mouse combo port(s)
  • 1 x DVI-D
  • 1 x DisplayPort
  • 1 x HDMI
  • 1 x LAN (RJ45) port(s)
  • 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C)
  • 2 x USB 3.2 Gen 1 Type-A
  • 2 x USB 2.0
  • 3 x Audio jack(s)
• Internal I/O Ports:
  • 1 x CPU Fan connector(s)
  • 3 x Chassis Fan connector(s)
  • 1 x AIO_PUMP connector
  • 1 x Lighting Control RGB Strip Header(s)
  • 2 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.2 Gen 1 port(s)
  • 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  • 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
  • 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
  • 1 x SPI TPM header
  • 5 x SATA 6Gb/s connector(s)
  • 1 x S/PDIF out header(s)
  • 1 x 4-pin EATX 12 V Power connector
  • 1 x 24-pin EATX Power connector(s)
  • 1 x 8-pin EATX 12V Power connectors
  • 1 x Front panel audio connector(s) (AAFP)
  • 1 x Clear CMOS jumper(s)
  • 1 x System panel connector
  • 1 x COM port header
• Accessories:
  • I/O Shield
  • 2 x SATA 6Gb/s cable(s)
  • 1 x M.2 Screw Package
  • 1 x Supporting DVD
  • User manual
• BIOS: 128 Mb Flash ROM, UEFI AMI BIOS
• Manageability: WOL by PME, PXE
• Operating System: Windows 10 64-bit
• Form Factor:
  • mATX Form Factor
  • 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.

Note

Currently out of stock

Available Quantity

0

UPC

192876667835

SKU

minglePRIME Z490M-PLUS

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Note

Currently out of stock

Available Quantity

0

UPC

192876694497

SKU

mingleROG STRIX B460-I GAMING

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Note

Currently out of stock

Available Quantity

0

UPC

192876694329

SKU

mingleROG STRIX H470-I GAMING

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Note

Currently out of stock

Available Quantity

0

UPC

889523021927

SKU

mingleH470 AORUS PRO AX

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: Z490M-ITX/AC
• Unique Feature
  • ASRock USB 3.2 Gen2
    • ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)
  • ASRock Super Alloy
    • Premium 60A Power Choke
    • 50A Dr.MOS
    • Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)
    • Sapphire Black PCB
    • High Density Glass Fabric PCB

  • 2.5G LAN

  • Intel 802.11ac WiFi

  • ASRock Steel Slots

  • ASRock Full Coverage M.2 Heatsink
  • ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)

  • ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  • ASRock Live Update & APP Shop

• CPU
  • Supports 10th Gen Intel Core Processors (Socket 1200)

  • Digi Power design
  • 7 Power Phase design

  • Supports Intel Turbo Boost Max 3.0 Technology
  • Supports Intel K-Series unlocked CPUs
  • Supports ASRock BCLK Full-range Overclocking
• Chipset
  • Intel Z490
• Memory
  • Dual Channel DDR4 Memory Technology
  • 4 x DDR4 DIMM Slots
  • Supports DDR4 4400+(OC) / 4333(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3200(OC) / 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory
  • Supports ECC UDIMM memory modules (operate in non-ECC mode)
  • Max. capacity of system memory: 64GB
  • Supports Intel Extreme Memory Profile (XMP) 2.0
  • 15 Gold Contact in DIMM Slots

• BIOS
  • 128Mb AMI UEFI Legal BIOS with multilingual GUI support
  • ACPI 6.0 Compliant wake up events
  • SMBIOS 2.7 Support
  • CPU, DRAM, PCH 1.05V, VCCIO, VCCSA Voltage Multi-adjustment
• Graphics
  • Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1
  • Graphics, Media & Compute: Microsoft DirectX 12, OpenGL 4.5, Intel Built In Visuals, Intel Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1
  • Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft PlayReady 3.0, Intel SGX Content Protection, UHD/HDR Blu-ray Disc
  • Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers
  • Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz

  • Supports DisplayPort 1.4 with max. resolution up to 4K x 2K (4096x2304) @ 60Hz
  • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
  • Supports HDCP 2.3 with HDMI 1.4 and DisplayPort 1.4 Ports
  • Supports 4K Ultra HD (UHD) playback with HDMI 1.4 and DisplayPort 1.4 Ports

• Audio
  • 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
  • Premium Blu-ray Audio support
  • Supports Surge Protection
  • PCB Isolate Shielding
  • Individual PCB Layers for R/L Audio Channel
  • Nahimic Audio

• LAN
  • 1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon RTL8125BG)
  • Supports Dragon 2.5G LAN Software
    • Smart Auto Adjust Bandwidth Control
    • Visual User Friendly UI
    • Visual Network Usage Statistics

    • Optimized Default Setting for Game, Browser, and Streaming Modes
    • User Customized Priority Control
  •  Supports Wake-On-LAN
  •  Supports Lightning/ESD Protection
  •  Supports Energy Efficient Ethernet 802.3az
  •  Supports PXE 1 x Gigabit LAN 10/100/1000 Mb/s (Intel I219V)
  •  Supports Wake-On-LAN

  •  Supports Lightning/ESD Protection
  •  Supports Energy Efficient Ethernet 802.3az
  •  Supports PXE
• Wireless LAN
  • Intel 802.11ac WiFi Module
  • Supports IEEE 802.11a/b/g/n/ac
  • Supports Dual-Band (2.4/5 GHz)

  • Supports high speed wireless connections up to 433Mbps
  • Supports Bluetooth 4.2 / 3.0 + High speed class II
• Slots
  • 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
  • 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ac module (on the rear I/O)
• Storage
  • 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 17), NCQ, AHCI and Hot Plug
  • 1 x Ultra M.2 Socket (M2_1), supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)

  • 1 x Ultra M.2 Socket (M2_2), supports M Key type 2280 M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
• Connector
  • 1 x RGB LED Headers
  • 1 x Addressable LED Headers
  • 1 x CPU Fan Connector (4-pin)
  • 1 x Chassis Fan Connector (4-pin)
  • 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
  • 1 x 24 pin ATX Power Connector
  • 1 x 8 pin 12V Power Connector
  • 1 x Front Panel Audio Connector
  • 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
  • 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
• Rear Panel I/O
  • 2 x Antenna Ports
  • 1 x PS/2 Mouse/Keyboard Port
  • 1 x HDMI Port
  • 1 x DisplayPort 1.4
  • 2 x USB 2.0 Ports (Supports ESD Protection)
  • 4 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (Supports ESD Protection)
  • 1 x USB 3.2 Gen1 Type-A Port (Supports ESD Protection)
  • 1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection)
  • 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED)
  • HD Audio Jacks: Line in / Front Speaker / Microphone
• Software and UEFI
  • Software
    • ASRock Motherboard Utility (A-Tuning)
    • ASRock Dragon 2.5G LAN Software
    • ASRock Polychrome SYNC
  • UEFI
    • ASRock EZ Mode
    • ASRock Full HD UEFI

    • ASRock My Favorites in UEFI
    • ASRock Instant Flash
    • ASRock Internet Flash
    • ASRock Easy RAID Installer
• Support CD
  • Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories
  • Quick Installation Guide, Support CD
  • 2 x SATA Data Cables
  • 2 x ASRock WiFi 2.4/5 GHz Antennas
  • 2 x Screws for M.2 Sockets
• Hardware Monitor
  • Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
• Form Factor
  • Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
• OS
  • Microsoft Windows 10 64-bit
• Certifications
  • FCC, CE

  • ErP/EuP ready (ErP/EuP ready power supply is required


Note

Currently out of stock

Available Quantity

0

UPC

Does not apply

SKU

mingleZ490M-ITX/AC

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Note

Currently out of stock

Available Quantity

0

UPC

824142212479

SKU

mingleZ490APRO

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Note

Currently out of stock

Available Quantity

0

UPC

889523022061

SKU

mingleH470I AORUS PRO AX

Rebate

15% of item price after purchase. Details to redeem rebate will be provided in shipment

Shipping

Free 2 day shipping

Return Policy

6 months free return. Return item within the time specified.

Product Description

Specifications

• Mfr Part Number: Z490 GAMING X
• CPU: LGA1200
  • Support for 10th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1200 package
  • L3 cache varies with CPU
• Chipset: Intel Z490 Express Chipset
• Memory:
  • Intel Core i9/i7 processors:
    - DDR4 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz memory modules
  • Intel Core i5/i3/Pentium/Celeron processors:
    - Support for DDR4 2666/2400/2133 MHz memory modules
  • 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
  • Dual channel memory architecture
  • Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  • Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  • Support for Extreme Memory Profile (XMP) memory modules
• Onboard Graphics:
  • Integrated Graphics Processor-Intel HD Graphics support:
    - 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
    * Support for HDMI 1.4 version and HDCP 2.3.
  • Maximum shared memory of 512 MB
• Audio:
  • Realtek ALC1200 codec
  • High Definition Audio
  • 2/4/5.1/7.1-channel
  • Support for S/PDIF Out
• LAN: Intel GbE LAN chip (1000 Mbit/100 Mbit)
• Expansion Slots:
  • 1 x PCI Express x16 slot, running at x16 (PCIEX16)
    * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
  • 1 x PCI Express x16 slot, running at x4
  • 3 x PCI Express x1 slots
    (All of the PCI Express slots conform to PCI Express 3.0 standard.)
• Multi-Graphics Technology: Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies
• Storage Interface:
  • 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A_SB)
  • 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2M_SB)
  • 6 x SATA 6Gb/s connectors
  • Support for RAID 0, RAID 1, RAID 5, and RAID 10
    * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
  • Intel Optane Memory Ready
• USB:
  • Chipset:
    - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel

    - 7 x USB 3.2 Gen 1 ports (5 ports on the back panel, 2 ports available through the internal USB header)

    - 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
• Internal I/O Connectors:
  • 1 x 24-pin ATX main power connector
  • 1 x 4-pin ATX 12V power connector
  • 1 x 8-pin ATX 12V power connector
  • 1 x CPU fan header
  • 4 x system fan headers
  • 2 x addressable LED strip headers
  • 2 x RGB LED strip headers
  • 6 x SATA 6Gb/s connectors
  • 2 x M.2 Socket 3 connectors
  • 1 x front panel header
  • 1 x front panel audio header
  • 1 x S/PDIF Out header
  • 1 x USB 3.2 Gen 1 header
  • 1 x USB 2.0/1.1 header
  • 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
  • 2 x Thunderbolt add-in card connectors
  • 1 x serial port header
  • 1 x Clear CMOS jumper
  • 1 x Q-Flash Plus button
• Back Panel Connectors:
  • 1 x PS/2 keyboard/mouse port
  • 1 x HDMI port
  • 1 x USB 3.2 Gen 2 Type-A port (red)
  • 5 x USB 3.2 Gen 1 ports
  • 2 x USB 2.0/1.1 ports
  • 1 x RJ-45 port
  • 6 x audio jacks
• I/O Controller: iTE I/O Controller Chip
• H/W Monitoring:
  • Voltage detection
  • Temperature detection
  • Fan speed detection
  • Overheating warning
  • Fan fail warning
  • Fan speed control
    * Whether the fan speed control function is supported will depend on the cooler you install.
• BIOS:
  • 1 x 256 Mbit flash
  • Use of licensed AMI UEFI BIOS
  • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• Unique Features:
  • Support for APP Center
    * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    - @BIOS
    - EasyTune
    - Fast Boot
    - Game Boost
    - ON/OFF Charge
    - RGB Fusion
    - Smart Backup
    - System Information Viewer
  • Support for Q-Flash Plus
  • Support for Q-Flash
  • Support for Xpress Install
• Bundled Software:
  • Norton Internet Security (OEM version)
  • cFosSpeed
• Operating System: Support for Windows 10 64-bit
• Form Factor: ATX Form Factor; 30.5cm x 24.4cm
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers
